Custom 14.8 Volt Lithium Ion Battery Packs , 8800mAh Ternary Lithium Ion Battery

Basic Information
Place of Origin:CHIAN
Brand Name:HB
Certification:ROHS
Model Number:
Minimum Order Quantity:Contact sales to get
Price:Contact sales to get
Packaging Details:Contact sales to get
Delivery Time:Contact sales to get
Payment Terms:T/T
Supply Ability:Contact sales to get
Detail Information
NominalVoltage:8800mAhNominalCapacity:14.8V
Warranty:1YearCycleLife:500Times
StandardDischargeCurrent:0.2C11
StandardChargeCurrent:0.2C
HighLight:lithiumpolymerbatterypack,largecapacitybatterypack

Product Description

18650 lithium battery pack 8800mAhy custom 14.8V ternary lithium ion battery



1.Technical Parameters



ItemRatingNote
CapacityTypical8800mAh

Discharge:1760mA ,

1760mA

Min8800mAh
Energy130.24Wh

Nominal Voltage

14.8V
AC Impedance Resistance≤200mΩ
Discharge Cut-off Voltage12.0V
Charge Voltage14.35V
Max. Charge Voltage14.40V
Charge TimeApprox 6.5h0.2C
Standard charge current1760mA0.2C
Max. Charge Current8800mA1.0C
Max. discharge current≤45℃1.0C
Shipments voltage≥14.05V
WeightApprox 800g
Operating TemperatureCharge0~+60℃
Discharge-10~+60℃

Storage Temperature



less than 1

month

-10~+60℃Recommended storage temperature: 20℃,at the transportation

less than 6

months

-10~+45℃





2.Application Area



Mainly used in solar backpack, solar hood, solar flashlight, solar car, solar sailing boat, solar airplane, BIPV, etc.





3.Safety instructions



HB lithium battery uses non-polluting materials and is produced with unique technology; it has fully passed UL safety certification, but as a lithium battery, like other types of cells, it has certain dangers when it is mechanically damaged. Therefore, the following precautions must be taken into consideration when handling and using HB lithium batteries:

1) It is forbidden to put the battery in water, and should be placed in a cool and dry environment during storage.

2) It is forbidden to use in the hot sunlight of moxibustion, otherwise it may cause battery overheating, fire or function failure.

3) It is prohibited to disassemble, open, chop or puncture the battery pack with metal.

4) It is forbidden to expose the battery or battery pack to heat or flame, to put the battery into the fire and to avoid storing it in direct sunlight.

5) It is forbidden to short-circuit batteries or batteries, and do not place multiple batteries in boxes or drawers at will to avoid shorting each other or by other metal objects.

6) It is prohibited to subject a battery or battery pack to mechanical shock.

7) In the event of leakage, do not contact the leaking liquid directly to the skin or eyes, if contact occurs, apply a large amount of water to flush the contact area.

8) Do not use non-special charging, which should be done in accordance with the manufacturer’s instructions.

9) Note the “plus positive ear” and “-negative ear “signs of the battery pack to ensure proper use.

10) Keep the battery pack clean and dry.

If the battery pack becomes extremely dirty, use a clean, dry cloth to wipe it.

12) Do not charge the battery pack for a long time.

13) The best performance and service life of the battery or battery pack can be obtained by charging and discharging at 15°C ~25°C.

14) Keep the original specification of the product for future reference.

15) Dispose of waste batteries or batteries in accordance with national environmental protection laws.
