101010 Ultra Thin Lithium Battery 4mah Custom 0.2c Standard Discharge Current

Basic Information
Place of Origin:CHINA
Brand Name:HB
Certification:ROHS
Model Number:HB101010 4mAh
Minimum Order Quantity:Contact sales to get
Price:Contact sales to get
Packaging Details:Contact sales to get
Delivery Time:Contact sales to get
Payment Terms:T/T
Supply Ability:Contact sales to get
Detail Information
NominalVoltage:3.0VNominalCapacity:700mAh
Warranty:1YearCycleLife:500Times
StandardDischargeCurrent:0.2C11
StandardChargeCurrent:0.2C
HighLight:thinlithiumpolymerbattery,thinlithiumionbattery

Product Description

Ultra-thin lithium battery 101010 polymer lithium battery 4mAh custom 3.7V



1.Technical Parameters



Part NoHB101010
Voltage Range3.0 to 4.2V
Nominal Voltage3.7 V
Nominal Capacity4mAh @ 4 mA to 3.0 V @ 23° C
Max. Discharge0.8mA continuous
Pulse Capability

Up to 2 mA

Varies according to pulse characteristics, temperature, cell history and the application. Consult

ABLE.

Typical Weight1 grams
Operating Temp-30° C to 75° C
Storage Temp-40° C to 75° C
Exterior/HousingLaminated Aluminum Foil
Terminals/Connec torNickel-Aluminum Tabs (Ni-Ni optional)
SafetyAL-MSDS/RD-004
TransportationExcepted from Regulations – see note 1

HB

2.Outline Dimensions and Appearance



This thickness will be swelling when high temperature storage or operation in high temperature.





  • Appearance

There shall be no such defect as scratch, flaw, crack, rust, leakage, which may adversely affect Commercial value of battery.
