501430 Li Polymer Battery 180mAh Bluetooth KC No Pollution ROHS Certification

Basic Information
Place of Origin:CHINA
Brand Name:HB
Certification:ROHS
Model Number:HB 501430 200mAh
Minimum Order Quantity:Contact sales to get
Price:Contact sales to get
Packaging Details:Contact sales to get
Delivery Time:Contact sales to get
Payment Terms:T/T
Supply Ability:Contact sales to get
Detail Information
NominalVoltage:3.7VNominalCapacity:200mAh
CycleLife:500TimesStandardDischargeCurrent:0.2C
StandardChargeCurrent:0.2CWarranty:1Year

Product Description

501430 Li Polymer Battery 180mAh Bluetooth KC No Pollution ROHS Certification



1. Technical Parameters



ItemRatingNote
CapacityTypical200mAh

Discharge:36mA ,

36mA

Min200mAh
Energy0.740Wh

Nominal Voltage

3.70V
AC Impedance Resistance≤100mΩ
Discharge Cut-off Voltage3.0V
Charge Voltage4.25V
Max. Charge Voltage4.30V
Charge TimeApprox 6.5h0.2C
Standard charge current40mA0.2C
Max. Charge Current200mA1.0C
Max. discharge current≤45℃1.0C
Shipments voltage≥4.05V
Operating TemperatureCharge0~+60℃
Discharge-10~+60℃

Storage Temperature



less than 1

month

-10~+60℃Recommended storage temperature: 20℃,at the transportation

less than 6

months

-10~+45℃





2. Application Area



Mainly used in solar backpack, solar hood, solar flashlight, solar car, solar sailing boat, solar airplane, BIPV, etc.





3. Safety instructions



HB lithium battery uses non-polluting materials and is produced with unique technology; it has fully passed UL safety certification, but as a lithium battery, like other types of cells, it has certain dangers when it is mechanically damaged.

It is forbidden to expose the battery or battery pack to heat or flame, to put the battery into the fire and to avoid storing it in direct sunlight.

It is forbidden to short-circuit batteries or batteries, and do not place multiple batteries in boxes or drawers at will to avoid shorting each other or by other metal objects.

It is prohibited to subject a battery or battery pack to mechanical shock.

In the event of leakage, do not contact the leaking liquid directly to the skin or eyes, if contact occurs, apply a large amount of water to flush the contact area.

Do not use non-special charging, which should be done in accordance with the manufacturer’s instructions.

Note the “plus positive ear” and “-negative ear “signs of the battery pack to ensure proper use.

Keep the battery pack clean and dry.

If the battery pack becomes extremely dirty, use a clean, dry cloth to wipe it.

Do not charge the battery pack for a long time.

The best performance and service life of the battery or battery pack can be obtained by charging and discharging at 15°C ~25°C.
